ANZWIN WINDOWS AND DOORS
Frame: 68.2mm X 20mm
Available size:Max Height: 2200mm
Max Panel Width: 2200mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Fin
Hardware : Chain Winder
U-Value : 3.2~5.8
SHGC: 0.25~0.67
Wind Load : N4
Frame: 68.2mm X 38mm
Available size:Max Height: 2400mm
Max Panel Width: 1200mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Fin
Hardware : SW Lock
U-Value : 3.2~5.8
SHGC: 0.25~0.67
Wind Load : N3
Frame: 60mm X 20mm
Available size:Max Height: 2200mm
Max Panel Width: 2200mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Fin
Hardware : Chain Winder
U-Value : 3.6~6.5
SHGC: 0.29~0.60
Wind Load : N4
Frame: 101.6mm X 38mm
Available size:Max Height: 2400mm
Max Panel Width: 1200mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : MA Lock
U-Value : 3.7~6.5
SHGC: 0.25~0.65
Wind Load : N4
Frame: 60mm X 20mm
Available size:Max Height:1700mm
Max Window Panel width: 900mm
Available glazing: Double Glazed up to 19mm IGU
Extrusion Profiles :6063-T5
Finish: Powder Coating or Anodized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead /
Subframe/Fin fixHardware : Winder
Frame: 60mm X 20mm
Available size:Max Height: 2400mm
Max Panel Width: 2500mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : /
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Fin
Hardware : /
U-Value : 2.6~6.0
SHGC: 0.29~0.67
Wind Load : N4
Frame: 101.6mm X 50mm
Available size:Max Height: 3000mm
Max Panel Width: 1500mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Sash Lock
U-Value : 3.5~5.4
SHGC: 0.25~0.55
50 BI-FOLD WINDOW
Frame: 50mm X 42mm
Available size:Max Height: 2100mm
Max Panel Width: 800mm
Double Glazed Sash
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Retractable Flyscreen
Fixing Method: Subsill+Angles
Hardware : Handle Lock
U-Value : 3.8
SHGC: 0.25~0.55
Frame: 101.6mm X 38mm
Available size:Max Height: 2400mm
Max Panel Width: 1200mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : D Lock
U-Value : 3.7~6.5
SHGC: 0.25~0.65
Wind Load : N4
Frame: 101.6mm X 50mm
Available size:Max Height: 2800mm
Max Panel Width: 1000mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Handle Lock
U-Value : 3.5~6.5
SHGC: 0.25~0.67
Wind Load : N3
Frame: 77.3mm X 58.5mm
Available size:Max Height: 3000mm
Max Panel Width: 800mm
Double Glazed Sash
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Retractable Flyscreen
Fixing Method: Subsill+Angles
Hardware : Handle Lock
U-Value : 3.7
SHGC: 0.25~0.55
