ANZWIN WINDOWS AND DOORS
Frame: 101.6mm X 50mm
Available size:Max Height: 2400mm
Max Panel Width: 2400mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Chain Winder
U-Value : 4.4~6.5
SHGC: 0.29~0.60
Wind Load : N3
Frame: 101.6mm X 50mm
Available size:Max Height: 5000mm
Max Panel Width: 5000mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : /
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : /
U-Value : 2.8~6.5
SHGC: 0.31~0.67
Wind Load : N3
Frame: 101.6mm X 50mm
Available size:Max Height: 2400mm
Max Panel Width: 2400mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Chain Winder
U-Value : 3.2~5.8
SHGC: 0.25~0.67
Wind Load : C4
Frame: 101.6mm X 50mm
Available size:Max Height: 2200mm
Max Panel Width: 900mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Winder
U-Value : 4.4~6.5
SHGC: 0.25~0.6
Frame: 101.6mm X 50mm
Available size:Max Height: 5000mm
Max Panel Width: 5000mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
U-Value : 2.6~5.8
SHGC: 0.3~0.67
Wind Load : C4
Frame: 152.4mm X 50mm
Available size:Max Height: 3000mm
Max Panel Width: 2000mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : D Lock
U-Value : 3.1~5.8
SHGC: 0.25~0.65
Wind Load : N6
Frame: 101.6mm X 38mm
Available size:Max Height: 2700mm
Max Panel Width: 1400mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : D Lock
U-Value : 3.2~5.5
SHGC: 0.3~0.65
Wind Load : N4
Frame: 101.6mm X 50mm
Available size:Max Height: 3000mm
Max Panel Width: 1800mm
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Timber reveal/Subsill+Subhead+Angles /Subframe/Fin
Hardware : Handle Lock
U-Value : 3.4~6.0
SHGC: 0.25~0.6
Wind Load : N3
Frame: 152.4mm X 50mm
Available Max Height: Customized
Max Width: Customized
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Subsill+Subhead+Angles /Subframe/Fin
Hardware : Customzied
U-Value : 3.2~5.5
SHGC: 0.25~0.65
Wind Load : N6
Frame: 152.4mm X 50mm
Available Max Height: Customized
Max Width: Customized
Single and Double Glazed Sash Options
Extrusion Profiles :6063-T5
Finish: Powder Coated / Anodized/Customized
Flynet : Fiberglass and Stainless Steel Security Mesh Available
Fixing Method: Subsill+Subhead+Angles /Subframe/Fin
Hardware : Customzied
U-Value : 2.8~5.5
SHGC: 0.25~0.65
Wind Load : N6
